MT Series

Strong, thermally stable, and all-weather outdoor display for enduring performance and minimal maintenance.

Good Heat Dissipation

The MT Series adopts a fully hollowed cabinet with a large air convection area, die-cast aluminum module shell, and thermal conductive adhesive for efficient cooling. Reflective coatings reduce heat absorption, keeping cabinet temperatures up to 15°C cooler than conventional models, ensuring stability and longevity.

Superior Waterproof Performance – IP66

Engineered for outdoor endurance, the MT Series features IP66-rated protection with a seamless design that resists high-pressure water jets and extreme weather. Delivers consistent, reliable operation across challenging environments, ensuring your outdoor LED screen remains stable and safe year-round.

Ultra Light & Slim Cabinet

The lightweight 25kg die-cast aluminum cabinet (960×960mm) and slim 91mm profile allow single-person installation, reducing labor and shipping costs. Strong yet compact, it provides a perfect balance of portability and structural stability for outdoor LED display setups.

Die-Cast Aluminium Cabinet

Precision-engineered with CNC technology, achieving cabinet flatness below 0.3mm for flawless splicing. The one-piece design enhances strength while minimizing deformation. A lightweight, handle-free form factor ensures easy installation and improved display alignment for outdoor LED video walls.

Advanced Module Design

Each module features four reinforced knobs supporting 21.94kg pull resistance for secure installation. Fully waterproof, fire-resistant, and compatible with left or right orientation. The elegant metal back shell improves cooling and protection—ideal for heavy-duty outdoor LED applications.

Die-Cast Aluminium Bottom Case

More durable than plastic, the die-cast aluminum bottom case offers IP65 waterproofing, deformation resistance, and non-flammable performance. Designed for rugged outdoor environments, it enhances protection, reliability, and stability for long-term outdoor LED screen usage.

Front Maintenance Access

Simplify service with front maintenance capability. Technicians can unlock the module using a professional tool, then open the back cover to access power, receiver, and hub components—ensuring quick, efficient maintenance without dismantling the entire LED display.

Wide Range of Applications

Built for durability and performance, the MT Series ensures stable operation in extreme outdoor environments. Ideal for highways, sports venues, transportation hubs, and public plazas, this versatile LED display delivers consistent brightness, protection, and reliability in any weather condition.
