CIP™ 26
The CIP 26 is a ported enclosure housing dual 6.5-inch woofers and a 1-inch tweeter — more low-end authority and headroom than a single-driver design, with the efficiency and mounting versatility to fit a wide range of installations.
That driver complement delivers across genres: the cinematic weight of film scores, the rhythmic punch of hip-hop, the raw drive of hard rock, and the detail of jazz and modern pop — all with clarity and presence to match the room.
Dante networking via a single RJ45 port provides native integration with any Dante or AES67 environment — stable, low-latency digital audio without analogue cabling. PoE++ delivers power and audio over that same cable, eliminating separate power runs and simplifying every install.
High efficiency. Versatile mounting. One cable. The CIP 26 is purpose-built for professional networked audio environments where performance and installation simplicity both matter.
• Compact two-way PoE++ powered loudspeaker
• Audio over IP: Dante® (AES67 compliant)
• Two premium 6.5” woofers, 1.5“ voice coil
• 1” Neodymium dynamic tweeter, 1“ voice coil
• Continuous power handling: 30 Watts
• Nominal impedance: 8 Ohms
• Coverage pattern (HxV): 120° x 75°
• Supports Power over Ethernet (PoE++ IEEE 802.3bt Type 3)
• Connectors: 1 x RJ45
• UL94V0 Flame-rated injection-molded plastic enclosure
• Unique oval port tube enclosure design
• Wall mount included
• Available in Black
Banquet Halls
Casinos
Auditoriums
Houses of Worship
Educational Facilities
Convention Centres
Corporate Environments
Restaurant
Bars
| Configuration | 2-way PoE++ Powered Speaker |
| Power Continuous (Watts) | 30 |
| Power Peak (Watts) | 60 |
| Sensitivity (1 W / 1 m) | 88 dB |
| Max SPL Peak | 103 dB |
| LF Driver | 2 × 6.5″ (165 mm) |
| Woofer Voice Coil | 1.5″ (38 mm) |
| HF Driver | 1 × 1″ (25 mm) Neodymium with Titanium Diaphragm |
| HF Voice Coil | 1″ (25 mm) |
| Nominal Coverage (HxV) | 120° × 75° |
| Frequency Range (-10 dB) | 65 Hz – 20 kHz (wall mounted) / 70 Hz (free space) |
| Frequency Response (±3 dB) | 75 Hz – 20 kHz (wall mounted) / 84 Hz (free space) |
| Nominal Impedance | 8 Ohms |
| Input Connector | 1 × RJ45 |
| Power Source | PoE++ IEEE 802.3bt Type 3 |
| Audio over IP | Dante® (AES67 compliant) |
| IP Mode | DHCP (Default) or Static |
| External Power Supply | DC In – 24 V, 2.7 A |
| Cat Cable Specification | Cat6a recommended |
| Amplifier | Class D, bi-amped |
| Internal DSP | Yes |
| Mounting Points for Wall Bracket | 2 × M6 (back of cabinet) |
| Wall Bracket | Included |
| Enclosure Design | Oval Port Tube Enclosure |
| Enclosure Material | UL94V0 Flame-rated Injection-molded Plastic |
| Black Finish | Matte Black Spray Paint |
| RAL # (Black) | 9004 |
| White Finish | n/a |
| RAL # (White) | n/a |
| Operating Temperature | -4°F – 140°F (-20°C – 60°C) |
| Logo Position on Grille | Bottom Center |
| Logo Size | 25 × 25 mm |
| Grille Material | Steel, Powder Coated |
| Grille Foam Backing | n/a |
| Grille Mesh Size (mm) | 5 × 2.5 |
| Net Weight | 12.8 lbs (5.8 kg) |
| Dimensions w/o Bracket (HWD) | 18.98″ × 8.58″ × 8.74″ (482 × 218 × 222 mm) |
| Dimensions with Bracket (HWD) | TBA |
